The Mark-10 TSC Force Measurement Test Stand is ruggedly built for testing up to 1,000 lb of compression or tension force.A large hand wheel requires little effort, even at high loads, and a precision Acme screw and nut ensure smooth operation over time. The stand includes a loading table with threaded holes for fixture or grip mounting and a solid metal base contains a storage pocket and holes for bench mounting. Available in vertical and horizontal orientations.

Features / Specifications:

• Maximum force: 1000 lb [5 kN]
• Maximum travel: 3.5 [89 mm]
• Compatible with all Mark-10 force gauges, accessories and grips
• Mounting holes for bench mounting
• Loading table with 25 #10-32 UNF holes for fixture mounting
• Precision Acme screw and nut
• Optional digital travel display
• The TSC / TSCH test stand is supplied with a tool kit, medium hook, large hook, and a 2 diameter compression plate.

Optional Equipment

• A wide range of force gauges and gripping fixtures
• Digital travel display (shown right) - 6 [152 mm] travel, 0.0005 [0.01 mm] resolution, 0.001 [0.03 mm] accuracy, SPC output for automated data collection.
• Horizontal / wall mounting kit - Set of mounting legs that attach to the test stand column in place of the base
• Custom modifications - Special modifications are available, including custom-designed fixtures, increased column length, and more. Call 1-800-336-5900 for more information
